processor

Intel LGA2011 pin series processor.

Southbridge

B85 Chipset series

memory

technology

Quad-channel DDR3 1333/1600/1866MHz

maximum capacity

128G

Memory slot

4*240PIN DDR3

Post I/O

PS/2 interface

1 (PS/2 mouse, PS/2 keyboard)

Ethernet

1 Realtek Gigabit NIC

Audio

1 (Mic-in, Line-out, Line-in)

USB port

6 USB2.0, 2 USB3.0

Internal connector

USB2.0

2 (one FUSB can switch out two USB2.0 interfaces);

USB3.0

2 (one FUSB can switch out two USB3.0 interfaces);

ATXPWR interface

1 standard 1x8PIN power socket; 1 standard 1x24PIN power socket

Audio

1 2*5PIN pin

M.2

M.2 SLOT*2 (supporting PCIE and SATA)

JTPM

1 2*7PIN pin

serial ata

6 SATA interfaces (SATA 3.0 * 4; SATA2.0*2）

JLPC

1 2*5PIN pin

SFAN

2 3-pin pins and 1 4-pin pin

CFAN

1 4PIN pin

PCIE

4 PCIE (PCIE X16*2; PCIE X1*1,PCIE X4*1）

environment

temperature range

working environment

Storage environment

Temperature:-10 ~ 60℃ Humidity: 5%~95%

Temperature: -40~85℃ Humidity: 5%~95%

Physical size

measure

283 mm x 216 mm
