工控主板

H110

H110  LGA1151 socket Intel6th  7th 8th i3-i5-i7 CPU
    MITX-IS6710S
    Processor Support  LGA1151 socket Intel6th  7th 8th i3-i5-i7 CPU
    CPU LGA1151 socket supported eg:i5 8400/G3900
    South bridge H110,Q170,C236
    Memory Technology framework dual DDR4 2400MHz SDRAM
    Socket 2*260pin ddr4  SO-DIMM.C236 southbridge could support ECC RAM
    I/O DC slot  1*1x4 Phoenix terminal power socket;1* 2x2 ATX power socket for optional
    HDMI&DP up DP down HDMI double layer socket, HDMI1.2, max resolution 4096x2160@24Hz;DP1.4, Max 4096x2304@60Hz
    CRT&COM1 up COM down VGA double layer socket, VGA max resolution 2560X1600@60Hz,COM RS232
    Ethemet 2*1000M lan RTL8111GN
    Audio 2*(Mic-in,Line-out), double layer socket
    USB 4*USB3.0(H110 only 2)
    Inner connect USB 2*USB2.0,2*USB3.0
    TPM 1* TPM  1.2 support
    COM 6  6*RS232, (COM2 support 422/485)
    PS 1
    GPIO 8 ways, double 5V
    LVDS 1,support signal /double channel 18/24 bit , max resolution 1920x1200@60Hz
    M.2 1,support PCIEX4 NVME SSD card, 2240,2280 2 models(sata channel could choose),only Q170,C236 support
    Mini-PCI e 1  MINI PCI e, support WIFI/4G/bluetooth
    MSATA 1 MINI PCI e,support msata SSD card
    SATA slot 4  , support SATA3.0(H110 only support 3), C236&Q170 support RAID model
    Watchdog output system reset
    interval recode 1-255s
    Power supply max Valtage standby:23.5V, max:100W(CPU i5 -8400)
    size size 170*170mm
    weight 0.5KG
